Single Non-Tensioning Collar and Cuff Press ALP-600U


  Click on above image to see video

Specification
PRODUCT NAME SINGLE
COLLAR & CUFF
MODEL ALP-600U
POWER 220V Single Phase, 0.14A
WEIGHT 565 lbs / 256 Kg
AIR CONSUMPTION 50 Liter / Cycle
STEAM CONSUMPTION 0.6 HP / 10 Kg/H
AIR PRESSURE 85 PSI / 0.6 Mpa
STEAM PRESSURE 85 PSI / 0.6 Mpa
AIR CONNECTION 3/8 B
STEAM CONNECTION Inlet 1/2 B, Outlet 1/2 B x 2
DIMENSION (mm)
(W x D x H) (inch)
730 x 1080 x 1237
28.7 x 42.5 x 48.7
